Technical Parameters:

1. Laser Power: Red 2500mW (638nm), Green 2500mW (525nm), Blue 3000mW (450nm)
2. Playback System: DMX512, Sound-activated, Auto, ILDA, Animation; laser shows within scenes selectable via DMX.
3. Display System: Color LCD screen; switchable between Chinese and English.
4. Imaging System: 30kpps high-speed scanning galvo; scan angle ±25°; input signal ±5V; linear distortion <2%.
5. Program Effects: Various beams, geometric patterns, animations, blanking effects; over 200 beam and animation effects.
6. Program Editing: DMX512 allows for programming various beam and animation shows; connection to a PC via control software enables the creation of more complex animation programs.
7. Laser Modulation: TTL and Analog options available (0–3kHz).
8. Beam Specifications: 6.5mm aperture, <1.2mrad divergence.
9. Total Power Consumption: 70W
10. Weight: 5.9kg
11. Dimensions: 230 x 230 x 193mm
